SPECIFICATIONS 2023 Newest technology in solar tracking for

---

 Control mode                                                                        Time + GPS

 Average tracking accuracy                                          0.1°- 2.0°(adjustable)

 Gear motor                                                                          24V/1.5A

Output torque                                                                         5000 N·M

Tracking power consumption                                       ＜0.02kwh/day

Azimuth angle tracking range                                                 ±45°

Elevation angle tracking range                                           45°

Max. wind resistance in horizontal                            ＞90MPH

Max. wind resistance in operation                            ＞54MPH

Material                                                                   H ot-dipped galvanized steel  ＞65μm

+                                                                                         Galvanized aluminum magnesium

 System guarantee                                                            3 years

 Working temperature                                                       -40℃F— +165F

Technical standard & certificate                                    CE 、TUV

Weight per set                                                               375LBS - 463LBS

Total power per set                                                         2000W - 6000

2023  Sunchaser 8 Sprcifications

Newest technology in solar tracking for the DIY community.

And you can do it yourself!

Applicable Solar Panels

 1650mm x 992mm
1956mm x 992mm
2256mm x 1134mm
2285mm x 1134mm
2387mm x 1096mm
2387mm x 1303mm (testing)
Other common size solar panels on the market.
We have supplied zrd-08 full automatic dual axis solar tracking system for more than 40 PV power stations around the world. Its simple structure, easy installation, good reliability and excellent power generation improvement effect have been widely recognized by customers.
